Description
Hikvision DS-2CD2343G2-LI2U/SL 4MP Two-Way Audio PoE CCTV Kit
Hikvision DS-2CD2343G2-LI2U/SL CCTV Kit helps you see what is happening, speak to visitors and respond to activity around your property. Detailed 4MP turret cameras combine AcuSense human and vehicle detection with built-in microphones, speakers and active light and sound warnings. Choose your recorder, camera quantity and storage to build a 4MP PoE CCTV kit around your premises.
This two-way audio CCTV system brings together wide-angle 2.8mm cameras, Smart Hybrid Light illumination and a Hikvision network recorder. Supplied black CAT5 cables simplify camera connections, while a choice of 4, 8 or 16 recording channels makes this Hikvision AcuSense camera kit suitable for homes, shops, offices and commercial properties. Camera quantities must suit the selected recorder’s channel capacity and available power.
Key Features
- ✓ Detailed 4MP video: Each camera captures up to 2688 × 1520 resolution, helping you review activity clearly.
- ✓ Two-way camera audio: Built-in dual microphones and a speaker let you listen and speak through a compatible, configured client.
- ✓ AcuSense detection: Human and vehicle classification helps focus notifications on relevant activity.
- ✓ Smart Hybrid Light: Infrared and white-light illumination provide flexible night viewing, with a stated range of up to 30 metres.
- ✓ Active deterrence: Configure white strobe lighting and audible warnings to respond to selected events.
- ✓ Wide-angle coverage: The 2.8mm fixed lens provides a 101° horizontal field of view.
- ✓ 120dB WDR: Helps balance bright backgrounds and shaded areas in the same scene.
- ✓ PoE+ camera connection: Carry power and video through one network cable, subject to the recorder’s total power budget.
- ✓ Flexible recorder options: Choose a 4, 8 or 16-channel Hikvision PoE NVR and an optional pre-fitted HDD.
- ✓ Outdoor camera protection: IP67-rated metal housings resist dust and water when correctly installed.
- ✓ Efficient recording: H.265+ compression helps manage storage and bandwidth requirements.
- ✓ Local and remote viewing: Connect a monitor to the NVR and configure Hik-Connect for access away from the property.
Why Choose This Product?
A 4MP PoE CCTV kit gives you a central place to view cameras and review recordings, with the flexibility to select the coverage and storage your property needs. The wide-angle cameras suit entrances, driveways and shared spaces, while camera audio adds context to the footage.
This Hikvision AcuSense camera kit also gives you ways to respond. Speak to a visitor, configure an audible warning or use the white strobe to draw attention to an event. Human and vehicle filtering helps make alerts more useful, with detection rules tailored to your installation.
Two-Way Audio and Active Deterrence
Each camera includes an arrayed dual microphone and a built-in speaker. This two-way audio CCTV system supports listening and talk-back through compatible software after setup. Enable audio recording on the NVR if you want sound stored alongside the video.
The cameras can trigger an audible warning and flashing white light for configured events. Adjust detection areas, schedules and warning settings to suit the location. The DS-2CD2343G2-LI2U/SL uses a white warning light.
Smart Hybrid Light and Clear Night Viewing
Smart Hybrid Light combines infrared and white-light illumination with three supplemental lighting modes. Infrared supports discreet black-and-white night viewing, while white light supports colour images after dark. Select the lighting mode that suits the scene and your preferences.
Illumination reaches up to 30 metres in suitable conditions. Actual night-time detail depends on the scene, positioning and available light. During the day, 120dB WDR helps retain detail in bright and shaded areas, while image noise reduction helps keep the picture cleaner.
AcuSense Human and Vehicle Detection
Configure motion detection, line-crossing and intrusion rules with human and vehicle filtering to monitor the areas that matter. This can help reduce notifications caused by unrelated movement. Correct aiming, suitable detection zones and event settings are needed for effective operation.
The cameras also support face detection. This detects a face in the image; it does not identify a person by name. Additional NVR analytics depend on the selected recorder, firmware and operating mode.
Recording, Storage and Hik-Connect
Select an optional pre-fitted hard drive to store footage on the recorder. Available choices are No HDD, 1TB, 2TB, 4TB, 6TB and 8TB. The No HDD option requires a compatible drive to be added before the NVR can store recordings. Recording retention depends on camera quantity, bitrate, drive capacity and schedule.
Connect a compatible monitor for local viewing and configure Hik-Connect for remote access. Remote viewing requires an internet connection; local recording can operate without internet access. Optional microSD storage in each camera is separate from the recorder’s HDD.
Technical Specifications
These specifications apply to the DS-2CD2343G2-LI2U/SL cameras with the listed 2.8mm lens. Recorder options are compared below.
| Specification | Details |
|---|---|
| Brand and camera model | Hikvision DS-2CD2343G2-LI2U/SL |
| Camera type | Fixed turret IP camera with AcuSense, Smart Hybrid Light and two-way audio |
| Image sensor | 1/3-inch progressive scan CMOS |
| Maximum camera resolution | 4MP: 2688 × 1520 |
| Lens | 2.8mm fixed focal lens; F1.6 aperture |
| Field of view | 101° horizontal, 57° vertical, 118° diagonal |
| Minimum illumination | Colour: 0.005 lux at F1.6 with AGC on; 0 lux with supplemental light |
| Shutter speed | 1/3 second to 1/100,000 second |
| Day/night switching | IR cut filter; day, night, automatic and scheduled switching |
| Supplemental illumination | Infrared and white light; Smart Hybrid Light with three lighting modes |
| Illumination range | Up to 30m; infrared wavelength 850nm |
| Main stream frame rate | Up to 25fps at 2688 × 1520 in 50Hz mode; up to 30fps in 60Hz mode |
| Video compression | Main stream: H.265+, H.265, H.264+ and H.264; sub-stream also supports MJPEG |
| Video bitrate | 32Kbps to 8Mbps |
| Wide dynamic range | 120dB true WDR |
| Image enhancement | BLC, HLC and 3D digital noise reduction |
| Audio hardware | Built-in arrayed dual microphone and speaker; two-way audio |
| Speaker specification | Maximum power consumption 2W; maximum sound pressure level 110dB measured at 10cm |
| Audio compression | G.711, G.722.1, G.726, MP2L2, PCM, MP3 and AAC-LC |
| Active warning | White strobe light and audible warning |
| Detection features | Motion detection, line crossing and intrusion with human/vehicle classification; face detection; video tampering alarm |
| Event actions | Recording and capture triggers, notifications, email, FTP/NAS/memory-card upload, audible warning and strobe flashing |
| Camera storage | microSD, microSDHC or microSDXC up to 512GB; card sold separately |
| Network interface | 1 × RJ45 10/100Mbps Ethernet port |
| Integration and clients | ONVIF Profiles S/G, ISAPI, SDK and ISUP; Hik-Connect, iVMS-4200 and Hik-Central |
| Privacy masking | 8 programmable polygon privacy masks |
| Camera power | IEEE 802.3at PoE+, Class 4, maximum 16W; alternatively 12V DC ±25%, 1A, maximum 12W |
| Housing and protection | Metal housing; IP67 dust and water resistance |
| Housing colour | White, GunMetal or Black, according to the selected option |
| Operating conditions | -30°C to +60°C; humidity up to 95%, non-condensing |
| Camera dimensions | 127.3mm diameter × 96.3mm height |
| Camera weight | Approximately 590g |
| Manual positioning | Pan 0–360°, tilt 0–75°, rotation 0–360° |
| Optional back base | Hikvision DS-1280ZJ-DM8 junction box; sold separately |
Choose Your Recorder and Kit Options
Select a recorder with enough channels for your chosen camera quantity and any planned expansion. Channel capacity and available camera power are separate limits.
| Specification | 4-Channel Option | 8-Channel Option | 16-Channel Option |
|---|---|---|---|
| Hikvision recorder | DS-7604NXI-K1/4P | DS-7608NXI-K1/8P | DS-7616NXI-K2/16P |
| IP camera channel capacity | Up to 4 cameras | Up to 8 cameras | Up to 16 cameras |
| Built-in PoE ports | 4 | 8 | 16 |
| PoE standard | IEEE 802.3af/at | IEEE 802.3af/at | IEEE 802.3af/at |
| Total recorder PoE budget | 50W | 75W | 200W |
| SATA drive bays | 1 | 1 | 2 |
| Local monitor connections | HDMI and VGA | HDMI and VGA | HDMI and VGA |
| Video compression | H.265+, H.265, H.264+, H.264 | H.265+, H.265, H.264+, H.264 | H.265+, H.265, H.264+, H.264 |
| Selectable kit storage | No HDD, 1TB, 2TB, 4TB, 6TB or 8TB | No HDD, 1TB, 2TB, 4TB, 6TB or 8TB | No HDD, 1TB, 2TB, 4TB, 6TB or 8TB |
Camera power planning: Each camera is rated at up to 16W over PoE+. At that maximum, 4 cameras require 64W, 8 require 128W and 16 require 256W. These figures exceed the corresponding recorder’s built-in PoE budget. Larger configurations may therefore require an additional correctly rated PoE+ switch or suitable separate camera power. Contact us to confirm the power arrangement for your selected configuration; additional power equipment is sold separately.
Storage selection: Your order includes only the HDD option selected. Two drive bays in the 16-channel recorder do not mean two drives are included. Recorder decoding and analytics limits depend on the model, firmware and enabled functions.
Official Datasheet
Download the exact Hikvision camera datasheet for detailed specifications and compatible mounting accessories.
Download DS-2CD2343G2-LI2U/SL Datasheet
What’s Included
- 1 × Hikvision PoE NVR: Your selected 4, 8 or 16-channel model.
- Hikvision DS-2CD2343G2-LI2U/SL 4MP cameras: Your selected quantity and housing colour, with 2.8mm lenses, dual microphones and built-in speakers.
- 20m black CAT5 network cables: One cable for each selected camera.
- 1 × 1.8m HDMI cable.
- 1 × USB mouse.
- Optional pre-fitted HDD: Included only when an HDD capacity is selected.
Sold separately: Monitor, DS-1280ZJ-DM8 back bases, camera microSD cards, additional power equipment and any extra cabling or mounting accessories required for your installation.
Ideal For
- Homes needing coverage of entrances, driveways and gardens.
- Shops and offices where camera audio and visitor communication are useful.
- Warehouses and commercial premises with several areas to monitor.
- Properties requiring human and vehicle alerts with active light and sound warnings.
- Customers who want local recording with remote access through Hik-Connect.
Installation & Compatibility
Plan the camera positions, cable routes, recorder capacity and total power requirement before installation. Connect cameras to suitable PoE+ ports using the supplied black CAT5 cables, keeping within the power budget. If an additional network PoE+ switch is used, connect and configure it appropriately with the NVR’s network; the recorder’s channel limit still applies.
Connect the recorder to a compatible monitor using the supplied HDMI cable, then activate the cameras and configure recording, audio, detection rules and remote access. Keep the NVR indoors in a dry, ventilated location. IP67 protection applies to the cameras; outdoor cable joints and entry points must be correctly sealed.
The cameras are fixed turret models with manual aiming. The optional Hikvision DS-1280ZJ-DM8 back base provides space for cable connections and is listed in the supplied camera datasheet. Choose suitable fixings and a matching finish where available.
Complete Your Installation
Add a compatible CCTV monitor for local viewing and a Hikvision DS-1280ZJ-DM8 back base where a camera junction box is required. Both are optional accessories sold separately. Our team can also help select additional PoE+ power equipment where needed.
