Description
What is included:
- 1x Hikvision HiLook NVR-104MH-C/4P or NVR-208MH-C/8P or NVR-216MH-C-16P
- Up To 16x Hikvision OEM IPC-280H-T
- 1x HDMI Cable (1.8m)
- 20M Cat5 Cable for each camera selected.
- Optional Pre-Fitted Hard Drive (Please select one at the top)
Hilook NVR-104MH-C/4P Features:
- Up to 4-ch IP camera inputs
- H.265+/H.265/H.264+/H.264 video formats
- Up to 1-ch@8 MP/5-ch@1080p decoding capacity
- Up to 40 Mbps incoming bandwidth
- 4 independent PoE network interfaces
Hilook NVR-208MH-C/8P Features:
- Up to 8-ch IP camera inputs
- H.265+/H.265/H.264+/H.264 video formats
- Up to 1-ch @ 8MP or 5-ch @ 1080P decoding capacity
- Up to 80 Mbps incoming bandwidth
Hilook NVR-216MH-C-16P Features:
- Up to 16-ch IP camera inputs
- H.265+/H.265/H.264+/H.264 video formats
- Up to 1-ch @ 8MP or 5-ch @ 1080P decoding capacity
- Up to 160 Mbps incoming bandwidth
Hikvision OEM IPC-280H-T Features:
- High quality imaging with 8 MP resolution
- Support Human and Vehicle Detection
- Smart Hybrid Light: advanced technology with long range
- Efficient H.265+ compression technology
- Support on-board storage up to 512 GB (SD card slot)
- Provide real-time security via built-in two-way audio
- Water and dust resistant (IP67)
Hilook NVR-104MH-C/4P Specifications:
Video And Audio
- IP Video Input 4-ch
- HDMI Output HDMI:,4K (3840 × 2160)/30Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz,VGA: ,1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz,
- VGA Input 1920*1080/60Hz，1280*1024/60Hz，1280*720/60Hz
- Incoming Bandwidth 40 Mbps
- Outgoing Bandwidth 80Mbps
- Audio Output1-ch, RCA (Linear, 1 KΩ)
- Two-Way Audio1-ch, RCA (2.0 Vp-p, 1kΩ)
Decoding
- Decoding Format H.265+,H.265,H.264+,H.264,MPEG4
- Decoding Capability 1-ch @ 8 MP / 4-ch @ 1080p
- Synchronous Playback 4-ch
Recording
- Resolution 8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Network
- Network Protocol : TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS
- Network Interface1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
PoE
- Interface: 4-ch
- Power: ≤ 50 W
- Standard IEEE: 802.3 af/at
- RAID
- RAID Type: No
- Auxiliary :Interface
- SATA1
- Capacity: Up to 8TB capacity for each disk
- USB Interface : 2 × USB 2.0
General
- Power Supply 48 VDC, 1.35 A
- Consumption ≤ 10 W (without enabling PoE)
- Working Temperature -10 to +55° C (14 to 131° F)
- Working Humidity 10 to 90 %
- Chassis 1U
- Dimension (W × D × H)265 × 225 × 48 mm (10.2″ × 8.9″ × 1.9″)
- ≤ 1 kg (2.2 lb)
HiLook NVR-208MH-C/8P Specifications:
Video And Audio
- IP Video Input 8-ch
- HDMI Output 1-ch, 4K (3840 × 2160)/30Hz, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
- VGA Output 1-ch, 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
- Incoming Bandwidth 80 Mbps
- Outgoing Bandwidth 80 Mbps
- Audio Output 1-ch, RCA (Linear, 1 KΩ)
- Two-Way Audio 1-ch, RCA (2.0 Vp-p, 1 k Ω)
Decoding
- Decoding Format H.265+,H.265,H.264+,H.264
- Decoding Capability 4-ch@1080p
- Synchronous Playback 8-ch
- Recording Resolution 8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF
Network
- Network Protocol TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS
- Network Interface 1, RJ-45 10/100 Mbps self-adaptive Ethernet interface
PoE
- Interface: 8, RJ-45 10/100 Mbps self-adaptive Ethernet interface
- Power: ≤ 80W
- Standard IEEE: 802.3 af/at
- RAID
- RAID Type No
- Auxiliary Interface
- SATA2 SATA interfaces
- Capacity Up to 8TB capacity for each disk
- USB Interface 2 × USB 2.0
General
- Power Supply 48V| ,2.5A MAX
- Consumption ≤ 15W
- Working Temperature -10 to +55º C (+14 to +131º F)
- Working Humidity 10 to 90 %
- Chassis 1U chassis
- Dimension (W × D × H)385 × 315 × 52 mm (15.2″× 12.4″ × 2.0″)
- ≤ 2.6 kg (5.7 lb)
Hilook NVR-216MH-C-16P Specifications:
Video And Audio
- IP Video Input 16-ch
- Incoming Bandwidth 160 Mbps
- Outgoing Bandwidth 160 Mbps
- HDMI Output 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
- VGA Output 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
- Audio Output 1-ch, RCA (Linear, 1 KΩ)
- Two-Way Audio 1-ch, RCA (2.0 Vp-p, 1kΩ)
Decoding
- Decoding Format H.265/H.265+/H.264/H.264+/MPEG4
- Recording Resolution 8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
- Synchronous Playback 16-ch
- Decoding Capability 2-ch @ 8 MP (25fps) / 4-ch @ 4MP (30fps) / 8-ch @ 1080p (30fps)
Network
- Network Protocol TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS
- Network Interface 1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
PoE
- Interface 16, RJ-45 10/100 Mbps self-adaptive Ethernet interface
- Power ≤ 200 W
- Standard IEEE 802.3 af/at
- Auxiliary Interface
- SATA 2 SATA interfaces
- Capacity Up to 6 TB capacity for each HDD
- Alarm In/Out 4/1
- USB Interface Front panel: 1 × USB 2.0; Rear panel: 1 × USB 3.0
General
- Power Supply 100 to 240 VAC，50 to 60Hz, 1 A
- Consumption ≤ 15 W (without enabling PoE and HDD)
- Working Temperature -10 °C to 55 °C (14 °F to 131 °F)
- Working Humidity 10 to 90 %
- Dimension (W × D × H)385 × 315 × 52 mm (15.2″ × 12.4″ × 2.0″)
- ≤ 3 kg (6.6 lb, without HDD)
Hikvision OEM IPC-280H-T Specifications:
Camera
- Image Sensor 1/2.7″ Progressive Scan CMOS
- Max. Resolution 3840 × 2160
- Min. Illumination Color: 0.01 Lux @ (F2.0, AGC ON),B/W: 0 Lux with IR
- Shutter Time1/3 s to 1/100,000 s
- Day & Night IR cut filter
- Angle Adjustment Pan: 0° to 360°,tilt: 0° to 75°,rotate: 0° to 360°
Lens
- Lens Type Fixed focal lens, 2.8mm
- Focal Length & FOV
2.8 mm, horizontal FOV 113°, vertical FOV 62°, diagonal FOV 134°
- Lens Mount M12
- Iris Type Fixed
- Aperture F2.0
DORI
- DORI
2.8 mm, D: 79 m, O: 31 m, R: 15 m, I: 7 m
Illuminator
- Supplement Light Type IR, White Light
- Supplement Light Range Up to 30 m
- Smart Supplement Light Yes
- IR Wavelength 850 nm
Video
- Main Stream
50 Hz:
12.5 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz:
15 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
- Sub-Stream
50 Hz: 12.5 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 15 fps (1280 × 720, 640 × 480, 640 × 360)
- Video Compression
Main stream: H.265+/H.265/H.264+/H.264,
Sub-stream: H.265/H.264/MJPEG
- Video Bit Rate 32 Kbps to 16 Mbps
- H.264 Type Baseline Profile, Main Profile, High Profile
- H.265 Type Main Profile
- Bit Rate Control CBR,VBR
- Region of Interest (ROI) 1 fixed region for main stream
- Scalable Video Coding (SVC) H.264 and H.265 encoding
Audio
- Audio Type Mono sound
- Audio Sampling Rate 8 kHz/16 kHz
- Environment Noise Filtering Yes
- Audio Compression G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC
- Audio Bit Rate 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)
Network
- Security Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address)
- Simultaneous Live View Up to 6 channels
- API Open Network Video Interface (Profile S, Profile T, Profile G),ISAPI,SDK
- Protocols TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP, UPnP
- User/Host
Up to 32 users
3 user levels: administrator, operator, and user
- Client iVMS-4200,Hik-Connect
- Web Browser
Plug-in required live view: IE 10, IE 11,
Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
- Wide Dynamic Range (WDR)120 dB
- SNR≥ 52 dB
- Day/Night Switch Day, Night, Auto, Schedule
- Image Enhancement BLC, HLC, 3D DNR
- Image Settings Rotate mode, saturation, brightness, contrast ,sharpness, gain, white balance, adjustable by client software or web browser
- Privacy Mask 4 programmable polygon privacy masks
Interface
- Ethernet Interface 1 RJ45 10 M/100 M self-adaptive Ethernet port
- On-Board Storage
Built-in memory card slot, support microSD/microSD HC/microSD XC card, up to 512 GB
- Built-in Microphone Yes, 1 built-in microphone
- Built-in Speaker Max. power consumption: 1.5 W, max. sound pressure level: 10 cm: 95 dB.
- Reset Key Yes
Event
- Basic Event Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm, exception
- Linkage Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger recording, trigger capture, audible warning, flashing light
General
- Power
12 VDC ± 25%, 0.66 A, max. 8 W,Ø5.5 mm coaxial power plug, reverse polarity protection,
PoE: IEEE 802.3af, Class 3, max. 9.5 W
- Material Metal & Plastic
- Dimension Ø110 mm × 102.7 mm (Ø4.33″ × 4.04″)
- Package Dimension 150 mm × 150 mm × 141 mm (5.9″ × 5.9″ × 5.6″)
- Weight Approx. 385 g (0.85 lb.)
- With Package Weight Approx. 586 g (1.3 lb.)
- Storage Conditions -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- Startup and Operating Conditions -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- Language English, Ukrainian
- General Function Heartbeat, anti-banding, mirror, password protection, password reset via email
- Flashing Light Yes
Approval
- EMC
CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021,
RCM: AS/NZS CISPR 32: 2015,
IC: ICES-003: Issue 7
- Safety
UL: UL 62368-1,
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017,
BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005
- Environment
CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006
- Protection- IP67: IEC 60529-2013
Viper Pro IPC-280H-T Specifications:
Camera
- Image Sensor 1/3″ Progressive Scan CMOS
- Max. Resolution 3K(3072*1728), 16: 9 picture ratio is more suitable for the most popular display
- Min. Illumination Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
- Shutter Time1/3 s to 1/100,000 s
- Day & Night IR cut filter
- Angle Adjustment Pan: 0° to 360°,tilt: 0° to 75°,rotate: 0° to 360°
Lens
- Lens Type Fixed focal lens, 2.8mm
- Focal Length & FOV
2.8 mm, horizontal FOV 98°, vertical FOV 54°, diagonal FOV 114°
- Lens Mount M12
- Iris Type Fixed
- Aperture F2.0
DORI
- DORI
2.8 mm, D: 63 m, O: 25 m, R: 12 m, I: 6 m
Illuminator
- Supplement Light Type IR, White Light
- Supplement Light Range Up to 30 m
- Smart Supplement Light Yes
- IR Wavelength 850 nm
Video
- Main Stream
50 Hz:
12.5 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz:
15 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
- Sub-Stream
50 Hz: 12.5 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 15 fps (1280 × 720, 640 × 480, 640 × 360)
- Video Compression
Main stream: H.265+/H.265/H.264+/H.264,
Sub-stream: H.265/H.264/MJPEG
- Video Bit Rate 32 Kbps to 8 Mbps
- H.264 Type Baseline Profile, Main Profile, High Profile
- H.265 Type Main Profile
- Bit Rate Control CBR,VBR
- Region of Interest (ROI) 1 fixed region for main stream
- Scalable Video Coding (SVC) H.264 and H.265 encoding
Audio
- Audio Type Mono sound
- Audio Sampling Rate 8 kHz/16 kHz
- Environment Noise Filtering Yes
- Audio Compression G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC
- Audio Bit Rate 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)
Network
- Security Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address)
- Simultaneous Live View Up to 6 channels
- API Open Network Video Interface (Profile S, Profile T, Profile G),ISAPI,SDK
- Protocols TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP, UPnP
- User/Host
Up to 32 users
3 user levels: administrator, operator, and user
- Web Browser
Plug-in required live view: IE 10, IE 11, Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
- Wide Dynamic Range (WDR)120 dB
- SNR≥ 52 dB
- Day/Night Switch Day, Night, Auto, Schedule
- Image Enhancement BLC, HLC, 3D DNR
- Image Settings Rotate mode, saturation, brightness, contrast ,sharpness, gain, white balance, adjustable by client software or web browser
- Privacy Mask 4 programmable polygon privacy masks
Interface
- Ethernet Interface 1 RJ45 10 M/100 M self-adaptive Ethernet port
- On-Board Storage
Built-in memory card slot, support microSD/microSD HC/microSD XC card, up to 512 GB
- Built-in Microphone Yes, 1 built-in microphone
- Built-in Speaker Max. power consumption: 1.5 W, max. sound pressure level: 10 cm: 95 dB.
- Reset Key Yes
Event
- Basic Event Motion detection (support alarm triggering by specified target types (human and vehicle),video tampering alarm, exception
General
- Power
12 VDC ± 25%, 0.66 A, max. 8 W,Ø5.5 mm coaxial power plug, reverse polarity protection,
PoE: IEEE 802.3af, Class 3, max. 9.5 W
- Material Metal & Plastic
- Dimension Ø110 mm × 102.7 mm (Ø4.33″ × 4.04″)
- Package Dimension 150 mm × 150 mm × 141 mm (5.9″ × 5.9″ × 5.6″)
- Weight Approx. 385 g (0.85 lb.)
- With Package Weight Approx. 586 g (1.3 lb.)
- Storage Conditions -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- Startup and Operating Conditions -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- Language English, Ukrainian
- General Function Heartbeat, anti-banding, mirror, password protection, password reset via email
- Flashing Light Yes
Approval
- EMC
CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021,
RCM: AS/NZS CISPR 32: 2015,
IC: ICES-003: Issue 7
- Safety
UL: UL 62368-1,
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017,
BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005
- Environment
CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006
- Protection IP67: IEC 60529-2013
Reviews
There are no reviews yet.
